TEL 3D81-000040-V2 processor module
Product Manual：
Product Features of TEL 3D81-000040-V2 Processor Module
Introduction: TEL 3D81-000040-V2 is a dedicated core processor board for TEL etching equipment, responsible for overall process calculations and system coordination.
Embedded high-performance processing chip with fast process logic operation response
Compatible with TEL T-3044SS etching machine, with strong compatibility with original equipment
Dual network port+multiple serial ports, supporting MES and HMI multi system communication
Built in complete safety interlock program, automatic triggering of protection shutdown in case of abnormality
Multi channel signal acquisition, precise reading of temperature, pressure, and flow sensor data
Electrical isolation PCB circuit, good anti electromagnetic interference effect in clean workshop
Triple hardware protection against overvoltage, overcurrent, and overheating reduces the risk of board damage
Standardized slot modular design, easy disassembly and replacement operation
Support online firmware upgrade, control program can be updated without disassembling the device
Local storage of running logs, quick retrieval and traceability of fault codes
V2 version optimizes power consumption, reduces heat generation during long-term continuous operation
Compatible with 3D81 control boards of the same series, flexible system expansion
Rail mounted cabinet installation, compatible with standard semiconductor control cabinet compartments
Original precision components, low failure rate during 7 × 24-hour production line operation
Compact board layout effectively saves installation space inside the cabinet
Conclusion: TEL 3D81-000040-V2 is the core computing unit of TEL wafer etching equipment, ensuring stable output of semiconductor production line processes.
