TEL 5044-000233-12 Printed Circuit Board
Product Manual：
TEL 5044-000007-12 Printed Circuit Board
1. TEL etching equipment dedicated functional PCB board, carrying machine power and signal paths
2. Multi layer high-density wiring, synchronous transmission of analog and digital multi class process signals
3. Independent isolation wiring to suppress electromagnetic interference in lithography and etching workshops
4. Thickened copper foil wiring, capable of withstanding high load currents and excellent temperature rise control
5. Precision metalized through holes, stable multi-layer circuit connections that are not easily broken
6. Multiple sets of I/O terminals, connected to external devices such as cavity sensors and solenoid valves
7. High temperature resistant solder mask coating, adapted to alternating temperature changes inside the cabinet
8. Strengthen the layout of the circuit, resist vibration, and reduce virtual welding faults during long-term operation
9. Built in filtering circuit ensures accurate and unbiased process timing signals
10. Reserve multiple testing points for convenient on-site fault measurement and maintenance
11. Card insertion installation, cabinet slot directly inserted, no need to modify wiring for disassembly and assembly
12. Integrated multi-channel communication wiring, connecting the main control of the whole machine with the interaction of the daughter board card
13. Built in short-circuit protection circuit, quickly cuts off the circuit under abnormal conditions
14. Components are arranged in zones, and local damage is easy to repair and replace separately
15. Original factory standard size, good compatibility for spare parts replacement
TEL 5044-000007-12 printed circuit board is an important circuit spare part for TEL semiconductor equipment, which realizes the transmission of various peripheral signals and power distribution of the whole machine, ensuring the stable operation of etching equipment.
Product detailed pictures：
5044-000233-12
