TEL 5880-000011-V1 PCB Rack Assembly
Product Manual：
TEL 5880-000011-V1 PCB Rack Assembly
Introduction: TEL 5880-000011-V1 is a specialized PCB installation rack assembly for Tokyo Electronic Semiconductor Machine, which integrates load-bearing, power supply, and signal transmission structures.
Multi slot standard slot, capable of carrying multiple control PCB boards simultaneously
Integrated backplane bus to achieve high-speed data interoperability among various boards
Built in shielding metal layer to resist RF and motor electromagnetic interference
Optimize the layout of air duct heat dissipation to reduce heat accumulation during high load operation
Reinforced metal frame, earthquake resistant and adaptable to continuous vibration conditions of the machine
Partition independent power supply circuit, single board failure does not affect the entire machine
Plug in buckle structure, no need to disassemble the rack body when disassembling the PCB
Board status indicator light, quickly locate the fault slot location
Original factory standard size, can be directly embedded into TEL series equipment chassis
Anti corrosion coating shell, suitable for clean and dust-free workshop environment
Integrate multiple external communication terminals to interface with the main control system of the entire machine
Internal wiring limit slot, neat wiring for easy maintenance and inspection
High temperature resistant insulation substrate, long-term 24-hour mass production and stable operation
Equipped with original positioning buckles, the installation of the board is precise and does not loosen
Suitable for various control board components of etching and thin film deposition equipment
Conclusion: TEL 5880-000011-V1 has reliable integration and strong scalability, and is a spare part for the core board carrier assembly of Tokyo Electronic Semiconductor Equipment.
Product detailed pictures：
