TEL CX81-050055-V2 Communication Module

Product Manual：

TEL CX81-050055-V2 Communication Module
Introduction: TEL CX81-050055-V2 is a dedicated original communication board for Tokyo Electronics etching and thin film equipment, responsible for multi unit data exchange and transmission of the entire machine.
Compatible with TEL CX81 series equipment chassis, original replacement parts
Integrated Ethernet and device internal bus dual communication channels
Support SECS/GEM semiconductor standard equipment communication protocol
Onboard electrical isolation circuit, shielding cavity electromagnetic interference
Built in data verification mechanism, transmission without packet loss or error codes
Multi channel parallel transmission and reception, synchronous transmission of process and alarm data
Power on automatic self check, quickly identify communication link faults

The firmware supports online upgrades without the need for disassembly and maintenance
Onboard status indicator light, visually viewing the working conditions of each channel
Multiple hardware protection circuits for short circuit, surge, and overvoltage
Standard card slot direct insertion installation, easy disassembly and replacement
Full board industrial reinforcement, suitable for long-term operation in dust-free workshops
Realize linkage communication between the main control, valve group, and motion board
Low power stable operation, reducing equipment heating faults
Long life original components, reducing the frequency of production line downtime
Conclusion: TEL CX81-050055-V2 communication transmission is stable and reliable, and is the core signal interaction component of TEL semiconductor process equipment.

Product detailed pictures：

CX81-050055-V2
