TEL E244-010007-21 Controller Module
Product Manual：
TEL E244-010007-21 Controller Module
Introduction: TEL E244-010007-21 is a dedicated main control module for Tokyo Electronic Etching and Coating Equipment, which coordinates equipment process logic and signal interaction, and provides spare parts for equipment maintenance and replacement.
E244-010007-21 is equipped with a dedicated processing chip, which has fast response to process timing calculations
Multiple I/O channels, collecting sensors and controlling air valves and transmission components
Built in optocoupler isolation circuit to resist plasma electromagnetic interference in the workshop
Support original equipment bus and stable communication with various sub boards
Equipped with signal filtering circuit to prevent misoperation caused by clutter
Plug in card standard version, easy and fast rack insertion and disassembly
Single channel independent indicator light, with intuitive and easy to troubleshoot fault locations
Three proof coating on the board surface, moisture and dust resistant, suitable for dust-free clean workshops
Industrial grade components that can operate continuously for 24 hours without interruption
Integrated security interlock program, automatic triggering of protection shutdown in case of abnormality
Store multiple sets of process formulas, switch processes without the need for re debugging
Compact card body design, saving installation space inside the chassis
Multiple circuit protection, with overcurrent and short-circuit protection functions
Factory complete parameter calibration, directly put into production on the machine
Stable wide temperature operation performance, suitable for high and low temperature working conditions in the workshop
Conclusion: TEL E244-010007-21 is compatible with TEL’s entire range of semiconductor process equipment, with precise and durable control, and good replacement compatibility.
Product detailed pictures：
E244-010007-21
