TEL E2B023-11 interface module
Product Manual：
TEL E2B023-11 interface module
Introduction: TEL E2B023-11 is a dedicated signal transfer interface module for etching, coating, and developing semiconductor equipment.
E2B023-11 multi-channel signal channel, connecting the main control and sensor units
Built in optocoupler isolation to isolate electromagnetic interference in the workshop
Support internal buses for multiple types of devices, ensuring distortion free signal transmission
Onboard filtering circuit to reduce misoperation caused by clutter
Plug in card standard structure, quick and easy disassembly and replacement
Industrial grade components, suitable for long-term operation in clean rooms
Three proof coating on the board, moisture-proof, dustproof, and resistant to chemical vapor
Equipped with channel indicator light, the fault location can be viewed intuitively
Accurate level matching, compatible transmission of digital and analog signals
Narrow card compact version, saving chassis rack space
Original factory standard terminals, with regular wiring that is not easily loose
Factory calibration of the entire machine, directly put into use on the machine
Wide temperature stable operation, suitable for high and low temperature environments in the workshop
Independent circuit protection, single channel faults do not affect each other
Modular design, convenient for equipment maintenance and expansion
Conclusion: TEL E2B023-11 is commonly used for repairing and replacing TEL semiconductor equipment, with stable and durable communication.
Product detailed pictures：
E2B023-11
