TEL TTLM02-12 2180-02107-V1 interface module
Product Manual：
TEL TTLM02-12 2180-02107-V1 interface module
Introduction: TEL’s original semiconductor equipment I/O signal adapter board is responsible for the signal exchange between cavity sensors and actuators.
Multiple digital input/output channels, collecting valve and limit switch signals
Electrical isolation circuit, isolating workshop RF electromagnetic interference
Onboard signal filtering to avoid signal jitter and false triggering of equipment
Integrated safety interlock circuit to ensure the safe operation of the process chamber
Equipped with operation indicator light, quickly locate wire breakage and short circuit faults
Specialized wiring terminal, connecting the main control and cavity sub components
Multi layer shielded PCB, strong and weak signal partition wiring without crosstalk
Industrial wide temperature element device, stable high and low temperature operation near the cavity
24V standard machine power supply, compatible with TEL etching and coating equipment
Support TTL level signal transmission and adapt to various sensors
Modular slot directly inserted into the chassis, easy to disassemble and replace
Comes with fault signal upload, real-time alarm prompt from the main control
Full board dust-proof protective coating, suitable for clean factory environment
Unified installation size, direct exchange of spare parts of the same model
Factory online aging test, stable long-term continuous operation
Conclusion: TEL TTLM02-12 2180-02107-V1 has stable signal transmission and is a core interface spare part for Tokyo Electronic Semiconductor Process Equipment.
Product detailed pictures：
TTLM02-12 2180-021107-V1
