TOKYO TME302B09DWG Robot Components

Product Manual：

TOKYO TME302B09DWG Robot Components
Introduction: TOKYO TME302B09DWG is a Japanese industrial equipment robot integrated component that integrates transmission, sensing, and drive structures, with precise positioning, and is suitable for continuous operation on semiconductor automation production lines.
Integrated servo drive and precision reducer, with smooth motion and sufficient torque
Built in high-precision encoder with minimal repeat positioning error
Multi degree of freedom linkage structure, suitable for wafer handling, picking and placing processes
Aluminum alloy reinforced shell, earthquake resistant and dust-proof, suitable for clean workshops
Built in electromagnetic brake, power-off locking to prevent workpiece from falling
Multi channel signal interface, can be directly connected to the main control communication and interaction of the whole machine

Closed loop motion control, high-speed start stop without shaking or deviation
Small integrated module, easy to disassemble and replace inside the equipment
Low friction transmission structure, low wear and low noise during long-term operation
Industrial wide temperature element device, stable operation around high and low temperature chambers
Equipped with fault feedback signals, quickly identify stuck or overloaded issues
Standard factory installation dimensions, directly replace old components of the same specifications
Isolate and protect the circuit to avoid electromagnetic signal interference in the workshop
Optimized heat dissipation structure, controllable temperature rise during 7 × 24-hour full load operation
Factory whole machine motion verification, good consistency of action, no need for repeated debugging
Conclusion: TOKYO TME302B09DWG has high motion accuracy, durability and stability, and is a specialized original robot accessory for repairing and replacing automated wafer transfer equipment.
