UAA326A02 HIEE300024R2 Digital Control Board
Product Manual：
#UAA326A02 HIEE300024R2 Digital Control Board
1. Model: UAA326A02 HIEE300024R2, excitation system digital control board
2. Multiple switch input and output channels to complete interlocking signal transmission and reception processing
3. Channel electrical isolation to isolate on-site electromagnetic interference
4. Onboard LED indicator light, intuitive display of channel working status
5. The input and output circuits are protected to prevent damage to the board caused by abnormal loads
6. Backboard slot installation, compatible with excitation system cabinet
7. Fast signal response speed, meeting the requirements of protection interlock timing
8. Channel self-test function, quickly identifying circuit disconnections and faults
9. Industrial wide temperature design, suitable for complex working conditions and environments in power plants
10. Surge suppression circuit to resist transient voltage surges in the power grid
11. High speed communication with the main control unit, stable synchronization of command data
12. Standard hardware interface, simple configuration and debugging operation
13. Anti vibration, suitable for long-term fixed installation of cabinets
14. Plug and unplug modular structure, easy maintenance and replacement
15. Low power consumption, supporting 7 × 24-hour uninterrupted operation
**Summary: UAA326A02 HIEE300024R2 digital control board is used to collect and output excitation system switch signals for interlocking, alarm logic processing, isolation protection, and stable operation.
