UAD149 3BHE014135R0011 UAD149A00-0-11 Controller Module
Product Manual：
ABB UAD149（3BHE014135R0011 / UAD149A00-0-11）
UAD149A00-0-11 (order number 3BHE014135R0011) is a Combi I/O hybrid control module for ABB AC 800PEC/AC 800M system, used for excitation control, servo/positioning, and process control.
Brand and model: ABB, UAD149A00-0-11, order number 3BHE014135R0011.
Series positioning: AC 800PEC dedicated Combi I/O, integrated DI/DO+AI/AO.
Core functions: excitation closed-loop, position/speed/torque control, high-speed I/O and communication.
I/O configuration: 8AI+8AO+16DI/16DO, 12-16 bit resolution.
Communication interfaces: SERCOS, Profibus DP, Modbus, Ethernet.
Control cycle: Position loop 500 μ s, excitation closed-loop<1ms.
Power supply: 24VDC (± 10%), typical power consumption 2-3W.
Physics: Approximately 155 × 105 × 95mm in size, weighing 0.3-1.68kg.
Environment: -25 ℃~+55/70 ℃, 5% -95% non condensing, IP20。
Isolation: Channel/system side electrical isolation, strong anti-interference.
Diagnosis: Channel status, power/communication/hardware fault alarm.
Installation: Standard rack/rail, supports hot swapping.
Certification: CE, UL, CSA, RoHS.
Applications: Generator excitation, servo drive, process automation.
Compatibility: AC 800PEC, AC 800M, System 800xA.
UAD149A00-0-11 communicates with multiple protocols through high-speed I/O and is a key I/O module for ABB’s high-end control systems.
