Valmet Metso A413654 Communication Interface Board

Product Manual：

Valmet Metso A413654 communication interface board, compatible with ND9000 series valve positioners, responsible for data exchange and protocol conversion.
Model: A413654, belonging to the Metso/Valmet Cisel series communication card.
Function: ND9000 locator dedicated communication interface, connecting the main control board with the upper system.
Protocol: Supports HART 5/7, Modbus RTU, compatible with DNA system.
Signal: Receive 4-20mA analog signals and convert them into digital signals for transmission.
Adaptation: Paired with A413125 main control board, used for ND9100/ND9200 locators.
Isolation: Optoelectronic isolation+lightning protection design, strong anti-interference.
Temperature: -20 ℃~+60 ℃, suitable for chemical, papermaking, and metallurgical working conditions.
Protection: Three proof coating, moisture-proof, anti-corrosion, and vibration resistant.

Installation: Standard Cisel rack slot, plug-in tool free.
Diagnosis: Onboard LED lights, communication status and fault are intuitive.
Power supply: 24VDC, low power consumption ≤ 3W.
Material: Fiberglass substrate+immersion gold process, stable solder joints with long service life.
Size: approximately 12 × 8 × 3.5cm, weighing approximately 0.5kg.
Status: Original factory shutdown, inventory/dismantled parts can be directly replaced.
Application: Valve remote monitoring, parameter configuration, fault diagnosis, and data uploading.
The Valmet Metso A413654 communication board is a key spare part for ND9000 locator and system communication, which is stable and reliable.

Product detailed pictures：

A413654

product video
