VENUS PC121000C control motherboard

Product Manual：

Product Features of VENUS PC121000C Control Motherboard
VENUS PC121000C is compatible with the main control operation unit of motion control equipment
Built in motion control chip, multi axis synchronous scheduling response is fast
Dual port independent communication, separate transmission of control commands and device data
Multiple IO terminals output directly, can be connected to sensors without the need for switching
Low power chip solution, low temperature rise during long-term operation
Built in hardware watchdog, automatically restarts and resumes operation upon system crash
Wide voltage DC input, suitable for workshop voltage fluctuation conditions

Solid state storage slot, stable storage of program data without loss
Multi serial port expansion, compatible with multiple servo and frequency converter communications
Multi layer shielded circuit to isolate electromagnetic interference signals from motors
Equipped with fault code indicator light, quickly locate abnormal points

Compact board body, suitable for equipment with small built-in installation space
Support offline storage of programs, and preset actions can also be executed offline
The VENUS PC121000C control motherboard is a specialized main control board for multi axis motion in automation equipment

Product detailed pictures：

PC121000C
