VMIC 332-000234-001E Printed Circuit Board
Product Manual：
VMIC 332-000234-001E Printed Circuit Board Product Features
VMIC 332-000234-001E is compatible with industrial VME bus industrial control equipment and can be installed in standard card slots
Multi layer precision circuit layout, precise and controllable signal routing impedance
Thickened copper foil circuit, stable current carrying capacity, suitable for high and low power components
Complete grounding power layering, significantly reducing electromagnetic crosstalk interference
Fully metalized through holes on the board, reliable interlayer conductivity, and not easy to break
Industrial FR-4 high temperature resistant substrate, capable of withstanding high and low temperature environments in workshops
Full coverage solder mask protective layer, anti oil, moisture-proof, and anti-oxidation
Gold finger thickened with gold plating treatment, wear-resistant insertion and removal, stable contact
Reserve multiple sets of standard testing points for convenient and efficient troubleshooting
Onboard multiple filtering circuit, analog digital signal separation without clutter
Anti vibration reinforced wiring design ensures that the equipment is not easily desoldered during continuous operation
Original factory precision silk screen labeling, clear component part numbers for easy replacement of parts
Integrate multiple signal acquisition channels to adapt to industrial control data acquisition scenarios
Standardized size specifications, can directly replace VMIC boards of the same series
Original factory circuit matching design, compatible with the entire VMIC industrial control system
VMIC 332-000234-001E printed circuit board is the core signal control board component of industrial control equipment
Product detailed pictures：
