Встроенный силовой модуль ADVANTECH ARK-3440
Руководство по продукту：
Встроенный силовой модуль ADVANTECH ARK-3440
Введение: ADVANTECH ARK-3440 is equipped with an embedded power module, suitable for fanless industrial control hosts, and stable wide voltage input, suitable for long-term operation in industrial workshops.
DC 9-34V wide voltage input, suitable for on-site voltage fluctuation conditions
AT/ATX standard power supply system, perfectly matched with industrial control motherboard
Low conversion loss, with a conventional power consumption of only about 38W for the entire machine
Built in overvoltage protection, automatically cuts off output in case of abnormal voltage
Integrated overcurrent and current limiting protection, components are not easily damaged by load overload
Equipped with short-circuit protection, the circuit is short circuited to prevent power from burning out
Equipped with overheat protection, automatic power reduction operation in high temperature environment
Низкая пульсация на выходе, reducing electromagnetic interference in the host signal
Metal shielding structure to resist electromagnetic noise from frequency converters
Adapt to fanless heat dissipation without additional heat dissipation noise
Moisture proof and dust-proof internal process, suitable for clean factory environment
Welding of seismic resistant components, equipment vibration without contact failure
Standard terminal wiring, разборка и замена без изменения схемы
Широкие температурные компоненты, stable operation from minus 20 к 50 ℃
Полная проверка заводского старения, low failure rate during 7 × 24-часовая непрерывная работа
Заключение: ADVANTECH ARK-3440 embedded power supply has multiple protections and stable power supply, ensuring uninterrupted operation of industrial control equipment and reducing maintenance downtime.
Подробные фотографии продукта：
ARK-3440
