Модуль изолированного вывода Allen Bradley 1771-OD16

Руководство по продукту：

Аллен Брэдли 1771 OD16 is a PLC-5 series 16 point isolated AC output module, solid-state thyristor, zero crossing trigger, used to control 120VAC AC loads, and is a commonly used spare part in old systems.
1. 16 isolated AC outputs, solid-state bidirectional thyristor (Triac)
2. Working voltage 74-138VAC (rated 120VAC), 47-63Гц
3. Single channel 5mA (min)~2A (max) continuous current
4. Module total continuous current ≤ 8A; surge 20A/100ms (repeatable every 2 seconds)
5. Zero crossing triggers activation to reduce surge current and interference
6. Channel ↔ Backboard photoelectric isolation, withstand voltage 1500VDC
7. Off state leakage current ≤ 3mA, to avoid small load misoperation

8. Backboard 5V power supply, typical power consumption 13W, backplane current 200mA
9. Each channel LED status indicator, equipped with operation/fault indicator lights
10. Built in surge suppression (MOV+RC), anti-interference and impact resistant
11. Suitable for standard racks such as 1771-A1B to A4B, occupying 1 slot
12. Supporting wiring arm 1771-WN/WH, with standardized wiring and easy maintenance
13. Working temperature range of 0-60 °С, suitable for conventional industrial environments
14. Compatible with PLC-5 full range controllers, commonly used for maintenance and replacement of old production lines
15. Used for 120VAC load control of contactors, электромагнитные клапаны, индикаторные лампы, small motors, и т. д.

Подробные фотографии продукта：

1771-OD16
