Процессорный модуль Allen Bradley 1785-V40L
Руководство по продукту：
Аллен Брэдли 1785-TR10BT Ethernet-трансивер
1785-TR10BT is a PLC-5 series AUI to 10BASE-T twisted pair Ethernet transceiver used to connect old AUI interface devices to standard RJ45 Ethernet, which is a commonly used spare part for the networking transformation of old PLC-5 systems.
1. Модель: 1785-ТР10БТ (PLC-5 series), AUI to 10M twisted pair transceiver
2. Интерфейс: 15 pin AUI (connected to PLC-5 communication card)+RJ45 (10BASE-T Ethernet)
3. Speed: 10 Мбит/с, half duplex, CSMA/CD protocol
4. Cable: Shielded Twisted Pair (STP), до 100 meters long
5. Источник питания: 12В постоянного тока, powered by AUI interface, low power consumption
6. Status LEDs: PWR (власть), TXD (transmit), RXD (receive), COL (conflict)
7. Основная функция: AUI → RJ45 protocol conversion, compatible with old PLC-5 internet connection
8. Network Protection: Conflict Detection, Jabber Control, Automatic Polarity Flip
9. SQE testing: with hardware switch, can be externally disabled, no need to disassemble
10. Изоляция: Электрическая изоляция, защита от помех, подходит для промышленных условий
11. Temperature: 0-60 ℃ for operation, -40-+85 ℃ for storage
12. Humidity: 5% -95% RH (without condensation)
13. Размер: Compact, both wall mounted and rail mounted
14. Совместимость: PLC-5/10/20/40/60/80 and other CPUs with AUI interface
15. Usage: Old PLC-5 connected to Ethernet, upper computer communication, data acquisition and monitoring
The Allen Bradley 1785-TR10BT transceiver achieves seamless conversion from AUI to RJ45 and is a key accessory for Ethernet upgrade of old PLC-5 systems.
Подробные фотографии продукта：
1785-V40L
