BOBST 0701238504 processor module

Руководство по продукту：

BOBST 0701238504 (701-2385-04) processor module
This module is the high-end CPU main control board of the Bobst 700 series control system, which is the core processing unit of the 703-KS control box. It is responsible for the overall logical operation, motion control, and bus scheduling of the machine, and is compatible with high-speed die-cutting/gravure printing/box pasting machines.
lass=”yoast-text-mark” />>Model analysis
Material Number: 0701238504 (Standard Writing 701-2385-04)
Series: 701 Series (700 System Controller/Processor Board)
Позиционирование: Main processor module, replacing the early 701-1106B, with stronger performance.

Core hardware configuration
Processor: 32-bit industrial grade CPU, clock speed ≥ 100MHz, fast processing speed
Memory: onboard RAM+Flash, storing system programs and user parameters
Bus: 700 series backplane bus+high-speed communication interface, multi board collaboration
Interfaces: Multi channel I/O, servo drive port, encoder feedback port, communication port.
>Electrical parameters
Источник питания: 24VDC ± 20%, powered by 704 series power modules
Потребляемая мощность: ≤ 15W, low heat design
Изоляция: photoelectric isolation+EMI filtering, resistant to strong electromagnetic interference in the workshop
Temperature range: -10 ℃~+65 ℃, suitable for printing and packaging workshop conditions.

function and role
Whole machine control: execute equipment motion logic, timing control, fault diagnosis
Motion control: servo/variable frequency axis linkage, high positioning accuracy and synchronization
Data processing: Collect sensor/encoder signals, calculate and output instructions
Communication management: interface with HMI, Модули ввода-вывода, upper system, обмен данными
Program storage: Built in system firmware and device parameters, saved when powered off.
