Bobst 703-KS control box

Руководство по продукту：

Bobst 703-KS control box
Bobst 703-KS is the standard control cabinet for the Bobst 700 series electrical control system, serving as the central electrical cabinet for die-cutting/gravure/box pasting machines, integrating the main control I/O、 Коммуникация, drive and power supply, whole machine signal and power distribution center.
Original factory standard electrical control box, compatible with EXPERTCUT die-cutting machine, S2000/S920 gravure printing machine, FLEXO box pasting machine.
Box structure: Steel plate welding+IP54 protection, dustproof, oil proof, waterproof, suitable for printing and packaging workshop working conditions.
Internal bus: 700 series backplane bus, slot mounted 701/704/705 series cards, plug and play.
Core configuration (common):
Main control: 701-1106B main control board
Коммуникация: 701-1091-03 communication module
I/O: 704-1108-01 Модуль ввода/вывода
Motor control: 704-1257-02 motor control board

Output control: 705-OC high-power output board
Источник питания: 704-1166-03 power board
Источник питания: three-phase 380VAC input, internally generating 24VDC, ± 15V, 5VDC to each board.
Heat dissipation: Top fan+side heat dissipation holes, forced air cooling, suitable for continuous full load operation.
Wiring: Front terminal block partition (power/control/signal), clearly labeled for easy maintenance.
Status display: The panel integrates power, операция, communication, and fault LEDs to visually determine the overall status of the machine.
Антиинтерференция: strong and weak electrical partition wiring, EMI filtering, optoelectronic isolation, to resist interference from frequency converters/motors.
Working environment: Temperature -10 ℃~+60 ℃, humidity 10% -90% (no condensation).
Установка: Floor standing/wall mounted optional, standard industrial size, seamlessly integrated with the equipment body.
