HP DMC-2142-DC24 Motion Control Board
Руководство по продукту：
The HP DMC-2142-DC24 motion control board is compatible with HP large format printing equipment and uses a 24V DC power supply four axis motion control motherboard
Standard DC24V DC power supply specification, compatible with internal power supply circuits of equipment
Support four axis independent synchronous control, both point motion and arc interpolation can be achieved
Equipped with a 32-bit processing chip, the motion calculation response is fast and the trajectory runs smoothly
Dual communication interface, Ethernet and RS232 serial port, stable connection to the upper computer
Each axis is equipped with dual encoder feedback, with high positioning repeatability and no offset
Built in PID dynamic compensation algorithm, smooth acceleration and deceleration to reduce mechanical impact
Comes with 8 digital inputs and 8 digital outputs, linked with external sensing components
Non volatile storage chip, power off to save motion programs and device parameters
Support electronic gear and electronic cam modes, suitable for printing and paper feeding stations
Onboard isolation circuit, isolating workshop static electricity and electromagnetic interference to prevent errors
100 pin standard integrated interface, neat wiring, easy disassembly and replacement
Built in multiple hardware protections, automatic cut-off for overvoltage, сверхток, and short circuit
Full board moisture-proof solder mask coating, suitable for long-term continuous operation in industrial workshops
Compatible with both servo and stepper drivers, with strong adaptability for equipment modification
Industrial grade surface mount components with low heat generation and low failure rate during long-term operation
Краткое содержание: The HP DMC-2142-DC24 motion control board has stable four axis synchronization performance, reliable communication, and can directly replace the original control motherboard of printing equipment.
Подробные фотографии продукта：
DMC-2142-DC24
видео о продукте
