IS210BPPCH1AC Multi Port Interface PCB Board

Руководство по продукту：

IS210BPPCH1AC Multi Port Interface PCB Board (GE Mark VIe System)
IS210BPPCH1AC is an I/O Package Processor Board (BPPC) for the GE Mark VIe (Speedtronic) turbine control system, used for signal processing and multi port communication of critical power equipment.
Модель: IS210BPPCH1AC (IS210 series, BPPC board)
Тип: I/O packet processor PCB board with multi port interface
Applicable system: GE Mark VIe turbine/gas turbine control system (not used for Mark VIeS)
Port: Dual Ethernet ports+multiple sets of I/O connectors for high-speed communication and signal conversion
Processor: onboard local CPU, integrated hardware watchdog and reset circuit
Источник питания: 9-16VDC wide voltage supply, onboard local CPU power supply, stable operation
Индикатор состояния: Red/green LED (7 red modes, 4 green modes), visually displaying the working status

Configuration: support BPPB → BPPC automatic reconfiguration, compatible with simplex/duplex/TMR the third mock examination redundancy
Process: Double sided SMT patch, compact size, fixed installation at all four corners
Диагностика: Onboard self diagnosis, can report faults to UCPA for quick positioning
Software: Supports ToolboxST/ControlST, can be configured and firmware upgraded online
Temperature: -25 ℃~+70 ℃, suitable for harsh environments such as power plants and oil and gas
Protection: IP20, standard cabinet installation, анти-электромагнитные помехи
Совместимость: Compatible with I/O components such as YAI CS1B, Y DIAS1B, Y DO AS1B, и т. д.
Приложение: Power generation, oil and gas, химическая промышленность, used for turbine/gas turbine control and data acquisition

Подробные фотографии продукта：

IS210BPPCH1AC
