JEOL 4TP-1B815 connector board

Руководство по продукту：

JEOL 4TP-1B815 connector board
1. Compatible with JEOL scanning electron microscope signal link, JEOL 4TP-1B815 achieves multi-component signal docking and transmission
2. Onboard precision connector base, precise plug alignment and stable contact
3. JEOL 4TP-1B815 line layout optimization to reduce signal crosstalk distortion
4. High precision etched circuit ensures lower transmission loss of weak current signals
5. Устойчивая к высоким температурам подложка, supporting long-term uninterrupted continuous operation of equipment
6. Complete solder mask protection layer to prevent copper foil oxidation and circuit short circuit
7. Standard pad structure, the connector is firmly soldered and not easily detached

8. Excellent flatness of the board surface, not easily warped or deformed during installation
9. Unified standard positioning hole, easy to disassemble, replace and maintain
10. JEOL 4TP-1B815 has reliable insulation performance and can withstand voltage fluctuations
11. Specification for metalized via process, ensuring long-lasting and stable interlayer conductivity
12. The silk screen pins are clearly labeled for easy maintenance and differentiation of signal channels
13. Adapt to changes in temperature and humidity inside the device, with good environmental adaptability
14. Excellent anti vibration performance, with tight connections under operating conditions
15. Original electrical specifications, perfectly compatible with the electronic control components of the entire machine
The JEOL 4TP-1B815 connector board is used as a signal transfer substrate and is compatible with the JEOL series scanning electron microscope.
