Jeol BP101498-03 Печатная плата генератора
Руководство по продукту：
Jeol BP101498-03 Печатная плата генератора
1. Adapt to JEOL JWS series wafer inspection scanning electron microscope scanning signal generation
2. Responsible for outputting scanning drive waveforms and controlling the trajectory of electron beam deflection
3. High precision waveform generation circuit ensures uniform and stable imaging scanning
4. Multi layer high-voltage compatible PCB substrate with outstanding heat resistance performance
5. Built in waveform filtering unit to reduce clutter interference and improve image quality
6. Precise impedance matching to maintain constant scanning signal amplitude
7. Optimization of power circuit layout to reduce circuit heat loss
8. Multiple overvoltage and overcurrent protection to prevent accidental damage to components
9. Metalized thick hole process, which is not easily oxidized and has poor contact after long-term operation
10. Accurate synchronization of output timing and deflection coil drive unit
11. Partition insulated wiring to prevent crosstalk between high-voltage areas
12. Strengthen the solder joints of electronic components and withstand the vibration of equipment operation
13. Reserved signal feedback channel for easy scanning and abnormal diagnosis
14. Стандартизированный размер платы, directly compatible with chassis card slots
15. Original factory whole machine debugging and calibration, запасные части той же модели могут быть заменены напрямую
The Jeol BP101498-03 generator circuit board serves as a carrier for generating scanning waveforms, outputting driving signals to support normal scanning imaging of electron microscopes.
Подробные фотографии продукта：
BP101498-03
