JEOL BP101544-02 Плата драйвера PCB
Руководство по продукту：
JEOL BP101544-02 Плата драйвера PCB
1. Compatible with JEOL electron microscope, responsible for outputting power drive signals
2. Drive deflection coils, приводы, and other loads to complete actions
3. Partition the wiring of power and signal circuits to reduce mutual interference
4. Add a peak absorption circuit to absorb the reverse electromotive force generated by load switching
5. Built in overcurrent and overheating protection to prevent abnormal load from burning out components
6. Select high heat-resistant circuit substrate to adapt to the high temperature environment of the chassis
7. Each drive channel is electrically independent to prevent mutual coupling and influence among channels
8. Precision plated through holes, which are less prone to poor contact when powered on for a long time
9. Fast signal tracking response, strictly following the overall operation timing of the machine
10. Strengthen the soldering process of electronic components and possess excellent seismic resistance characteristics
11. Equipped with feedback sampling circuit, real-time monitoring of output working conditions
12. Insulation isolation design, suitable for high voltage operation scenarios of equipment
13. Specification for the outline dimensions of the board, which can be directly inserted into the equipment card slot
14. Surface solder mask prevents dust and water vapor from corroding the circuit
15. Factory performance debugging completed, supporting direct replacement of spare parts of the same model
JEOL BP101544-02 driver PCB card outputs controllable power signals to ensure precise and stable operation of various execution components of the electron microscope
