JEOL BP101667-01 Printed Circuit Board
Руководство по продукту：
JEOL BP101667-01 printed circuit board is a Japanese electronic analytical instrument dedicated original circuit board, responsible for signal transmission and circuit control functions.
1. Original factory specification design, perfectly compatible with JEOL mass spectrometry series equipment
2. Precise wiring ensures stable transmission of high-speed signals
3. Accurate impedance control to reduce signal distortion
4. The substrate has stable performance and can adapt to the continuous operation conditions of the instrument
5. Отличные изоляционные характеристики, effectively preventing short circuits in power lines
6. Copper foil has strong adhesion and is not easy to peel off after long-term operation
7. High precision via process ensures reliable circuit conductivity
8. Equipped with electromagnetic protection to reduce external signal interference
9. The board surface is well protected, влагостойкий, пыленепроницаемый, and anti-oxidation
10. Strict dimensional tolerance, high compatibility for disassembly and replacement
11. Multiple signal points to meet the interaction of various sensing signals
12. Equipped with basic circuit protection to reduce the risk of component damage
13. Компактная структура, fully utilizing the internal installation space of the instrument
14. The wiring is clear and organized, making it easy for later maintenance and troubleshooting
15. Using high-quality substrates for long-lasting and stable service life
The JEOL BP101667-01 printed circuit board is commonly used for signal transmission in JEOL mass spectrometer control systems.
