JEOL BP102002-00 Vacuum Control Panel
Руководство по продукту：
JEOL BP102002-00 Vacuum Control Panel
1. Specially designed for centralized control of vacuum systems in JEOL electron microscopy equipment
2. Real time collection of vacuum gauge signals, precise monitoring of chamber vacuum degree
3. Output control signals to drive vacuum pumps and valves to start and stop in an orderly manner
4. Built in signal filtering circuit to resist electromagnetic interference in high-voltage environments
5. Precision PCB wiring reduces vacuum signal transmission loss
6. Industrial grade electronic components that support long-term continuous operation of equipment
7. Equipped with a status feedback loop for quick identification of vacuum anomalies
8. Stable power conditioning circuit, буферизация колебаний и воздействий напряжения
9. Standardized plug-in terminals, easy and fast on-site disassembly and replacement
10. Excellent insulation design to prevent leakage risk under complex working conditions
11. Широкая температурная адаптация, able to withstand temperature changes inside the chassis
12. Reliable metalized hole process, less prone to poor contact during long-term use
13. Компактная структура платы, matching equipment with reserved installation positions
14. After undergoing a complete aging test at the factory, the consistency of spare parts is high
15. Match the timing logic with the original factory program to ensure smooth vacuum extraction process
The JEOL BP102002-00 vacuum control panel is the core component of the electron microscope vacuum system, which coordinates vacuum monitoring and pump valve linkage control.
Подробные фотографии продукта：
БП101734-02
