JEOL BP102072-00 Analog Input Electronic Module
Руководство по продукту：
JEOL BP102072-00 Analog Input Electronic Module
1. Compatible with JEOL electron microscope, responsible for multi-channel analog voltage signal acquisition
2. Implement buffering, кондиционирование, and level conversion for weak analog signals
3. Adopting a channel isolation architecture to block external interference from conducting inward
4. High precision passive filtering network, filtering out high-frequency electromagnetic clutter
5. Balance line impedance and reduce attenuation of long-distance signal transmission
6. Equipped with transient suppression devices to resist line surge impact
7. Independent acquisition circuit to avoid mutual coupling and interference between channels
8. Wide temperature PCB substrate, suitable for continuous heating conditions of the chassis
9. Metallic through holes provide long-lasting conductivity, delaying contact oxidation and aging
10. The signal sampling rate is stable, meeting the real-time monitoring requirements of the entire machine
11. Сварка усиления компонентов, resistant to equipment operation vibration
12. Upload the processed standardized signal to the main control unit
13. Компактная модульная конструкция, precise matching of equipment installation positions
14. Surface solder mask reduces the risk of leakage caused by dust and moisture
15. Original factory electrical parameter calibration, faulty modules can be directly replaced
JEOL BP102072-00 analog input electronic module collects various sensing analog signals to provide accurate status data support for the main control system.
Подробные фотографии продукта：
BP102072-00
видео о продукте
