JEOL BP102093-00 Printed Circuit Board
Руководство по продукту：
JEOL BP102093-00 Printed Circuit Board
1. JEOL precision equipment internal core signal transmission substrate
2. Integrate multiple signal lines to achieve signal interconnection between different modules
3. Reasonably separate strong and weak electrical wiring to reduce electromagnetic interference with each other
4. Select stable substrates to adapt to continuous high temperatures in the chassis
5. High quality through-hole electroplating process to delay metal contact oxidation
6. The impedance of the wiring is matched to ensure the quality of signal transmission
7. Onboard simple filtering circuit to reduce the impact of external clutter
8. Separate line partitioning to avoid short-circuit hazards under high voltage
9. Component solder joint strengthening treatment to withstand equipment vibration
10. Transmitting control signals and sensing acquisition signals
11. Reserve test contacts for easy maintenance and testing in the future
12. The structural dimensions strictly follow the original factory standards and are suitable for disassembly and assembly
13. Insulation performance meets standards and is suitable for high-voltage working environments of equipment
14. Solder mask protective layer reduces dust and moisture erosion on the circuit
15. The factory electrical inspection is qualified, and the faulty board can be directly replaced
JEOL BP102093-00 printed circuit board builds internal electrical circuits to ensure stable transmission of various signals.
