JEOL BP102355-00 Printed Circuit Board

Руководство по продукту：

JEOL BP102355-00 Printed Circuit Board
1. Supporting JEOL precision instruments, JEOL BP102355-00 carries the power supply and signal wiring of the entire machine
2. Weaken external electromagnetic interference and ensure smooth signal transmission
3. Equipped with electrical isolation to prevent momentary high voltage damage to electronic components
4. Reasonably plan wiring, separate power supply lines and signal lines
5. Высококачественный материал подложки, not easily damaged by circuit aging after long-term use
6. Fixed in standard card slot, легко разбирать и ремонтировать, and convenient to operate
7. Normal computer room temperature and humidity environment can operate smoothly and continuously
8. Each group of lines does not interfere with each other, and there will be no signal crosstalk during operation

9. Basic protection function when abnormal current occurs
10. The welding is firm and reliable, and can withstand the vibration of equipment operation without easy detachment
11. Reasonable line impedance reduces signal transmission losses
12. Общее энергопотребление низкое., and the heat generated during operation is very small
13. The size interface is consistent, and the old version JEOL BP102355-00 can be directly replaced
14. Strictly tested and qualified upon leaving the factory, it can be put into normal use immediately after installation
15. The overall structure is sturdy and suitable for long-term uninterrupted operation of equipment
The JEOL BP102355-00 printed circuit board is an original circuit board with stable and durable internal circuit conductivity for JEOL equipment

Подробные фотографии продукта：

BP102355-00
