JEOL CP010451-00 Communication Module

Руководство по продукту：

JEOL CP010451-00 Communication Module
1. Compatible with JEOL electron beam semiconductor testing equipment chassis system
2. The JEOL CP010451-00 communication module is responsible for data exchange and transmission between various boards
3. Support multi-channel parallel data transmission and reception, coordinate communication instructions between modules
4. Built in signal filtering circuit to reduce electromagnetic interference in the computer room
5. Standard card insertion specifications, chassis slots can be directly replaced
6. JEOL CP010451-00 Communication Module Adapts to Device Native Communication Protocol
7. Equipped with electrical isolation protection to prevent the spread of signal circuit faults

8. Controlled impedance routing ensures the integrity of high-speed communication signals
9. The definition of connector pins should be consistent with the original accessories
10. Long term continuous communication condition, stable and uninterrupted link
11. Communication link abnormalities can be proactively alerted and reported to the main control
12. Adapt to the constant temperature and dust-free operating environment of the electron microscope room
13. The communication channel is independently partitioned, making troubleshooting convenient
14. Low data transmission delay ensures closed-loop control timing of the entire machine
15. Follow JEOL original hardware and electrical design standards
The JEOL CP010451-00 communication module serves as the system communication hub, enabling data exchange between various functional boards inside the chassis.

Подробные фотографии продукта：

CP010451-00
