JEOL H10080FD RF Filter

Руководство по продукту：

JEOL H10080FD RF Filter
1. Compatible with JEOL electron microscope series equipment, with original factory standard installation dimensions
2. JEOL H10080FD RF filter effectively filters out RF clutter interference
3. Excellent out of band suppression performance, reducing signal noise interference
4. Low insertion loss in passband ensures normal signal transmission
5. Internal precision resonant structure, stable frequency characteristics
6. Металлическая защитная оболочка, resistant to external electromagnetic interference
7. Tolerate internal temperature changes of the device and prevent performance drift

8. Interface matching with the entire machine circuit, directly replace and install
9. JEOL H10080FD RF filter power carrying meets equipment operating conditions
10. Block harmonic signals to avoid affecting precision imaging control
11. Компактная структура, suitable for narrow installation space of chassis
12. The welding of the circuit is reliable and has strong long-term stability during operation
13. Suppress RF signal crosstalk and improve the overall signal-to-noise ratio of the machine
14. Dustproof and earthquake resistant design, suitable for continuous operation environment of equipment
15. Purifying the RF signal link and reducing equipment malfunctions
The JEOL H10080FD RF filter is a key component of the RF circuit, ensuring the purity and stability of electron microscopy signals.

Подробные фотографии продукта：

H10080FD
