Jeol MP003424-01 Communication Interface Module

Руководство по продукту：

Jeol MP003424-01 Communication Interface Module
1. Compatible with JEOL precision equipment, Jeol MP003424-01 achieves data communication and docking of various components of the equipment
2. Shielding external electromagnetic interference, stable data transmission without packet loss
3. Electrical isolation protection to prevent instantaneous high voltage breakdown of internal chips
4. Convert communication signal formats and connect data exchange between different boards
5. High quality PCB board, less prone to circuit failures during long-term power on operation
6. Slot insertion installation, легкая разборка и замена операции
7. Sustainable and stable operation under normal temperature and humidity conditions in the computer room
8. Multiple communication channels work independently without causing signal interference to each other

9. Automatically activate protection in case of abnormal current, reducing the probability of hardware damage
10. Welding is firm and stable, resisting the vibration generated by equipment operation
11. Optimize line impedance to reduce losses during data transmission
12. Low operating power consumption and minimal heat generation during operation
13. Unified interface specifications, can directly replace old Jeol MP003424-01
14. The whole machine has been tested and verified before leaving the factory, and can be used without debugging on the machine
15. Overall durability is good, meeting the long-term continuous operation requirements of the instrument
The Jeol MP003424-01 communication interface module is an original matching module for reliable internal data transmission of JEOL devices

Подробные фотографии продукта：

MP003424-01

видео о продукте
