JEOL MP004068 Analog Input/Output Module

Руководство по продукту：

JEOL MP004068 Analog Input/Output Module
1. Adapt to JEOL electron beam detection equipment measurement and control system
2. JEOL MP004068 Analog Input/Output Module sends and receives multiple analog signals
3. Channels are independent of each other, isolating various sensing analog signals
4. Equipped with a built-in filtering circuit, effectively filtering out transmission clutter
5. Unified module specifications, chassis slots can be directly replaced
6. JEOL MP004068 Analog Input/Output Module Matching Whole Machine Voltage Standard
7. Channel electrical isolation to prevent circuit faults from affecting each other
8. Refine circuit design to reduce analog signal distortion

9. The definition of wiring terminals should be consistent with the original module
10. Длительная непрерывная работа, stable accuracy of data acquisition and output
11. Channel fault information can be pushed to the main control system
12. Adapt to the constant temperature and dust-free working environment of the electron microscope room
13. Each channel is independently arranged, and maintenance does not interfere with each other
14. Rapid signal response meets the requirements of closed-loop monitoring
15. Compliant with JEOL original circuit design specifications
The JEOL MP004068 analog input/output module is an analog signal interaction unit that realizes sensor data acquisition and analog output regulation.

Подробные фотографии продукта：

MP004068
