JEOL PH00688-0 Communication Module
Руководство по продукту：
1. The JEOL PH00688-0 communication module is responsible for data transmission between instrument hosts
2. Stable transmission and reception of operating parameters, control instructions, and various data information
3. Equipped with signal noise reduction design to reduce communication interference caused by external environment
4. Card slot insertion installation, disassembly and maintenance without the need for large-scale disassembly
5. Low operating power consumption and minimal temperature rise during long-term operation
6. Build data transmission channels for various control boards inside the electron microscope
7. The connection is not easily disconnected or disconnected under equipment vibration during operation
8. After connecting to the entire system, the communication protocol is automatically paired and docked normally
9. Multiple data transmission lines operate independently, and single channel faults do not affect each other
10. Adapt to the data exchange and transmission of internal components in semiconductor precision equipment
11. Separate the wiring of communication lines and power supply lines to avoid mutual interference
12. Conventional computer room temperature controlled environment can provide continuous and stable communication 24/7
13. The protective coating on the board prevents dust accumulation and reduces poor contact issues
14. Automatically retry connection when data transmission is abnormal to protect the communication link
15. The JEOL PH00688-0 communication module has passed the factory communication test and can be put into use immediately after installation
The JEOL PH00688-0 communication module efficiently completes the data exchange of the entire machine, with stable and reliable connections.
Подробные фотографии продукта：
PH00688-0
