JEOL PP01103-1 Electronic Board Module

Руководство по продукту：

JEOL PP01103-1 Electronic Board Module
1. Applied to JEOL electron microscopy to achieve analog signal acquisition and level conditioning
2. Amplify weak sensing signals and filter out high-frequency electromagnetic clutter
3. Adopting signal isolation scheme to block external interference transmission
4. Each acquisition channel is independent of each other to prevent signal coupling and crosstalk
5. Equipped with transient suppression components to resist line surge impact
6. Select high-precision devices to maintain signal acquisition accuracy
7. Heat resistant substrate material, suitable for long-term high temperature working conditions of the chassis
8. Metallized through holes resist oxidation and extend equipment lifespan

9. After the signal conversion is completed, transmit the data to the main control system
10. Component reinforcement welding, with excellent seismic performance
11. Модульная структура, size matching equipment installation slots
12. Excellent substrate insulation, suitable for high voltage operating environment
13. Surface solder mask to reduce dust and moisture that can cause malfunctions
14. Preset status monitoring circuit for easy maintenance and repair
15. Original factory parameter calibration, spare parts can be directly replaced
The JEOL PP01103-1 electronic board module completes the sorting and conversion of sensing signals, providing reliable measurement data for the main control system.

Подробные фотографии продукта：

PP01103-1
