JEOL PTTD2-2010-0914 Printed Circuit Board

Руководство по продукту：

JEOL PTTD2-2010-0914 Printed Circuit Board
1. Suitable for JEOL precision equipment, JEOL PTTD2-2010-0914 is responsible for conducting internal circuits of the equipment
2. Block external electromagnetic interference and ensure smooth signal transmission
3. Circuit isolation protection to avoid instantaneous high voltage damage to components
4. Regular wiring layout, integrating power supply and various signal lines
5. Высококачественный материал подложки, not prone to aging and problems when powered on for a long time
6. Standard card position fixed, easy to disassemble and repair
7. Can work stably and continuously in a regular computer room environment

8. The line partitions are independently routed, and there will be no crosstalk between them
9. Comes with basic overcurrent protection to reduce the probability of damage in case of abnormal current
10. The original factory welding is firm and can withstand the vibration of equipment operation without easy detachment
11. Reasonable impedance adaptation to reduce losses during signal transmission
12. The overall power consumption is not high, and the heat generation during operation is low
13. Unified size interface, can directly replace old version JEOL PTTD2-2010-0914
14. After passing the factory inspection item by item, it can be installed and run normally
15. The structure is sturdy and reliable, suitable for long-term uninterrupted operation of instruments
JEOL PTTD2-2010-0914 printed circuit board is an original matching circuit board for stable and durable internal circuit transmission of JEOL equipment

Подробные фотографии продукта：

PTTD2-2010-0914
