JEOL SM-71400 Controller

Руководство по продукту：

JEOL SM-71400 Controller
1. Compatible with JEOL electron beam semiconductor detection equipment
2. JEOL SM-71400 controller executes closed-loop control of motion mechanism
3. Receive instructions and output drive signals, collect position feedback
4. Built in filtering circuit to reduce the impact of electromagnetic interference
5. Module specification standard, supports direct replacement installation
6. JEOL SM-71400 controller compatible with device communication bus
7. Equipped with surge protection to safeguard internal circuit components

8. Optimize power routing to ensure stable driving signals
9. The connector pins are consistent with the original accessories
10. Long term load operation, stable control accuracy
11. Report abnormal movement information to the main control system in a timely manner
12. Adapt to the working conditions of the constant temperature and dust-free electron microscope room
13. Separation of strong and weak electrical regions for convenient fault maintenance
14. Quick command response and precise positioning timing
15. Follow JEOL original hardware design standards
The JEOL SM-71400 controller is a motion driven control unit that manages the operation of precision mechanisms such as stages.

Подробные фотографии продукта：

SM-71400
