JEOLPH01143-2 Controller Module

Руководство по продукту：

JEOL PH01143-2 Controller Module
1. Compatible with JEOL electron beam semiconductor detection equipment
2. JEOL PH01143-2 controller module controls equipment actions and interlocking signals
3. Receive main control instructions, output switch values to drive peripherals
4. Optoelectronic isolation design to reduce electromagnetic interference
5. Standard card insertion style, can directly replace the original module
6. JEOL PH01143-2 Controller Module Compatible with Whole Machine Signal Standard
7. Built in surge protection to protect internal circuits
8. Optimize wiring and stabilize signal transmission

9. The interface pins are consistent with the original accessories
10. Can operate continuously and stably for a long time without interruption
11. Proactively report channel faults to the main control system
12. Adapt to the constant temperature and dust-free environment of the electron microscope room
13. Circuit partition layout for convenient maintenance
14. Rapid signal response ensures action timing
15. Follow JEOL original hardware design specifications
The JEOL PH01143-2 controller module serves as a switch control unit to achieve coordinated control of various mechanisms in the equipment.

Подробные фотографии продукта：

PH01143-2
