KYOSAN AR10108PA340 Printed Circuit Board
Руководство по продукту：
The KYOSAN AR10108PA340 printed circuit board is a dedicated PCB for high-voltage power supply, suitable for semiconductor equipment power supply modules.
1. High voltage wiring process, with insulation performance meeting standards and strong withstand voltage capability
2. High Tg substrate, высокая термостойкость, not easily deformed after long-term operation
3. Thick copper foil design, capable of carrying high currents without generating heat
4. Multi layer precision wiring, signal and power partition isolation
5. Thickened solder mask for protection, влагостойкий, пыленепроницаемый, and oil resistant
6. Reserve standard testing points for convenient fault detection
7. Thickened electroplating on the hole wall, making it less prone to cracking during cold and hot cycles
8. Neat layout, suitable for assembly of original power components
9. KYOSAN AR10108PA340 printed circuit board is resistant to electromagnetic interference, ensuring stable operation in clean rooms
10. Low coefficient of thermal expansion, stable size under high and low temperature conditions
11. The solder joints are firmly attached, resistant to earthquakes and vibrations, and not easily detached
12. Anti ion migration process, no leakage in high humidity environment
13. Standardized hole positioning, легкая разборка и замена
14. Integrated high-voltage capacitors and transformer matching wiring channels
15. KYOSAN AR10108PA340 printed circuit board has low loss and good overall energy consumption control effect
KYOSAN AR10108PA340 printed circuit board has outstanding reliability and is the core circuit carrier of high-voltage power supply for wafer equipment.
Подробные фотографии продукта：
AR10108PA340
