RENSHAW M-5225-0521-02 Parallel Interface Board
Руководство по продукту：
RENSHAW M-5225-0521-02 Parallel Interface Board
Введение: RENSHAW M-5225-0521-02 is a parallel signal adapter board for Renishaw grating, which realizes the transmission and conversion of grating and main control signal.
Compatible with various Renishaw grating rulers and encoder signal output docking
Multiple parallel signal independent channels, signal transmission does not interfere with each other
Optoelectronic isolation circuit, isolating equipment from electromagnetic frequency conversion interference
Built in multi-layer circuit protection against static electricity, перенапряжение, and short circuit
Real time conversion of grating position signal upload control system
Onboard fault indicator light, quickly locate communication abnormalities
Standard card slot installation, convenient cabinet disassembly and replacement
Sinking gold solder pads, difficult to oxidize and have poor contact during long-term workshop use
Three proof coating treatment, moisture and dust resistant, suitable for clean production lines
Precise wiring design, distortion free transmission of signals at small positions
Support internal bus of the device and high-speed interaction with the motion controller
Reinforce PCB board to withstand continuous vibration environment of equipment
Reserved testing points for easy troubleshooting and detection operations
Industrial wide temperature material, supporting uninterrupted equipment operation throughout the day
Suitable for semiconductor lithography and detection precision positioning equipment
Заключение: RENSHAW M-5225-0521-02 has stable signal transmission and strong anti-interference ability, and is a core adapter board for precision positioning equipment grating system.
Подробные фотографии продукта：
M-5225-0521-02
видео о продукте
