SYS68K/CPU-40B/16 single board computer
Руководство по продукту：
SYS68K/CPU-40B/16 single board computer
SYS68K/CPU-40B/16 is a 68040 industrial grade single board computer based on VME bus under FORCE (BOSCH REXROTH), used for high reliability industrial control and embedded systems.
Core processor: MC68040, with a main frequency of 25MHz, integrated FPU and MMU.
Memory configuration: Standard 16MB DRAM, onboard 128KB Flash EPROM (supports online programming).
Storage and boot: 2 system EPROM slots, 1 boot EPROM, supporting local boot.
Bus architecture: VMEbus with 32-bit high-speed DMA controller (FGA-002).
Serial port: 4 channels can be configured with RS-232/422/485, leading out from the front panel.
Parallel interface: 8-bit parallel interface with 4-bit handshake signal.
Network and I/O: Integrated Ethernet and SCSI interfaces; Optional EAGLE-01C extended floppy drive control.
Operating System: Compatible with VxWorks, Linux, and Windows embedded systems.
Источник питания: 24В постоянного тока, power consumption of about 25W, supports redundant power supply.
Temperature range: -40 от ℃ до +85 ℃, wide temperature industrial grade.
Protection and heat dissipation: Fanless conduction heat dissipation, PCB reinforcement, anti vibration and impact.
Size and weight: 174 × 96 × 60mm, approximately 1.0kg, VME standard board.
Diagnosis and maintenance: Onboard status LED, supporting hardware self-test and fault code output.
Compliance certification: UL, CE, FCC Class A, подходит для суровых промышленных условий.
Typical applications: DCS, робототехника, управление процессом, rail transportation, military automation.
This single board computer has the core advantages of 68040 high performance, VME bus high reliability, and wide temperature fanless, and is a commonly used core board in key industrial systems that are old but still in service.
Подробные фотографии продукта：
SYS68K/CPU-40B/16
