UAD149A1501 3BHE014135R1501 блок управления возбуждением
Руководство по продукту：
UAD149A1501 (3BHE014135R1501) excitation control unit
UAD149A1501 is an excitation control unit in industrial power systems and generator control, used to regulate the excitation current of synchronous generators and achieve precise control of generator output voltage and power factor. This module is widely used in power plants, подстанции, и крупномасштабные промышленные энергетические системы.
1、 Расположение модуля
The excitation control unit is a core component of the generator automation control system. Регулируя ток возбуждения, it achieves stable output of the generator voltage and supports reactive power regulation and grid stability control of the system.
2、 Основные функции
Control the excitation current of synchronous generator
Stable generator terminal voltage and power factor
Support automatic/manual excitation regulation mode
Fault detection and protection output
Communicate with the upper controller or protective relay
Provide status monitoring and alarm functions
3、 Технические характеристики
High precision voltage control
Can quickly respond to load changes and maintain stable generator output.
Closed-loop excitation control
Real time adjustment of excitation through feedback signals to achieve dynamic control.
Multi mode operation
Support automatic adjustment, manual operation, and remote control.
Полная функция защиты
Including over excitation, under excitation, and temperature anomaly protection.
Надежность промышленного уровня
The module adapts to high temperature, высокая влажность, and electromagnetic interference environments to ensure long-term stable operation.
UAD149A1501 3BHE014135R1501 Подробные фотографии продукта：
