DSQC202 YB560103-AC/8 Single Board Computer
Product Manual：
The DSQC202 (YB560103-AC/8) single board computer is the core control board of ABB Robot S4/S4C+system, responsible for overall operation, motion control, and communication management. It is original industrial grade, stable and durable, and has strong compatibility.
1. ABB original model DSQC202, material number YB560103-AC/8, robot main computer board.
2. Compatible with ABB IRB 6400, IRB 2400 and other S4/S4C+controller platforms.
3. Integrated embedded industrial grade processor, responsible for system computation, motion planning, I/O management, and communication scheduling.
4. Onboard SRAM/Flash, storing system programs, user programs, and process parameters.
5. Comes with RS232 and DeviceNet/CANopen interfaces, connecting the teaching pendant, I/O module, and upper computer.
6. Equipped with hardware real-time clock and watchdog, automatic reset in case of abnormalities, improving system reliability.
7. LED indicator lights display power, operation, and fault status for quick diagnosis.
8. Standard cabinet slot installation, reliable gold finger contact, easy disassembly and assembly.
9. Industrial grade wide temperature operation, resistant to workshop vibration, dust, and electromagnetic interference.
10. The backplane is powered by 24VDC, with low power consumption, low heat generation, and supports long-term continuous operation.
11. Supports RobotWare system firmware and is compatible with S4/S4C+all series of robot software.
12. Built in hardware self-test and fault log, combined with a teaching pendant to quickly locate problems.
13. Multi layer PCB, original process, anti-aging, corrosion resistance, long service life.
14. No complex debugging required, same model replacement can be installed and used immediately, reducing downtime.
15. Widely used as the control core for ABB robot production lines such as welding, handling, spraying, and assembly.
The DSQC202 (YB560103-AC/8) single board computer is the control heart of S4/S4C+robots, with stable computation, complete interfaces, durability and reliability. It is the preferred original spare part for repairing and replacing the old ABB robot main control board.
Product detailed pictures：
