Genesis GHW25Z-08108 Power System
Product Manual：
Genesis GHW25Z-08108 Power System
1. High power DC power supply system for semiconductor process equipment
2. Multiple output channels, capable of supplying power to multiple sets of loads simultaneously
3. Low output ripple and excellent process power supply stability
4. Voltage and current closed-loop control, high parameter adjustment accuracy
5. Equipped with multiple hardware protections for overvoltage, overcurrent, short circuit, and overheating
6. Built in fault monitoring, capable of storing historical fault records
7. Rack mounted modular structure, suitable for machine cabinet installation
8. Air cooled cooling design, supporting continuous production for 7 × 24 hours
9. Support communication bus, connect with device master to achieve remote control
10. Fast dynamic response to load, adaptable to sudden changes in process load
11. Hardware electrical isolation to suppress electromagnetic interference in the workshop
12. High power density effectively saves cabinet space
13. Panel status indicator light, convenient for quick troubleshooting on site
14. Alarm signal output, can be connected to the whole machine safety interlock circuit
15. Standardized interface, easy and convenient disassembly and replacement of spare parts
The Genesis GHW25Z-08108 power system is the core power supply unit for semiconductor etching and coating equipment, providing stable and controllable DC power output for machine process components.
Product detailed pictures：
GHW25Z-08108
product video
