Silicon Graphics Si5350/51-20QFN-EVB Generator Evaluation Board
Product Manual：
Silicon Graphics Si5350/51-20QFN-EVB Generator Evaluation Board
1. Specialized clock chip debugging and evaluation board
2. Comes with a reference crystal oscillator, no need for an external reference clock
3. Multi channel clock signal output, convenient for instrument testing
4. Dual mode power supply with USB and external voltage
5. The supporting software can customize the output clock frequency
6. Support multi gear voltage switching and debugging
7. Reserved I2C interface, flexible configuration for external controller
8. Visual inspection of operational fault status through indicator lights
9. Wide output frequency coverage, suitable for multiple scenarios
10. Line impedance optimization with minimal clock signal jitter
11. Equipped with testing points, probe detection is convenient
12. Compatible with multiple Si5350 and Si5351 chips
13. Tested chip power consumption for convenient solution selection
14. Compact size, convenient desktop debugging and placement
15. Common accessories for chip development and equipment maintenance
In summary, the Silicon Graphics Si5350/51-20QFN-EVB generator evaluation board is a practical testing accessory for clock development and maintenance.
Product detailed pictures：
Si5350/51-20QFN-EVB
