TEL 2L08-05105-11 PCB board
Product Manual：
TEL 2L08-05105-11 PCB board compatible with TEL semiconductor etching equipment
1. High density wiring saves installation space
2. Accurate impedance and low signal transmission loss
3. Large area grounding, anti electromagnetic interference
4. Heat dissipation through holes, no high temperature during long-term operation
5. Sinking gold solder pads, not easily oxidized and prone to virtual soldering
6. Separate the wiring of strong and weak electricity, without interfering with each other
7. Differential long lines with low signal delay
8. High temperature resistant board, suitable for hot and cold environments
9. Reserve shielding space to prevent static electricity
10. Micro porous process, stable interlayer conductivity
11. Clean solder mask, moisture-proof and dustproof
12. Component reinforcement, resistant to equipment vibration
13. Original factory wiring, matching corresponding models
14. Comes with signal acquisition circuit
15. Standard hole position, easy to replace and disassemble
TEL 2L08-05105-11 PCB board transmission equipment control signal to ensure stable production of the machine
Product detailed pictures：
2L08-05105-11
