Jeol MP003380-00 Backboard
Руководство по продукту：
Jeol MP003380-00 Backboard
1. Used for JEOL electron microscope cabinets as a base for various types of board connectors
2. Integrate multiple slots to connect the power bus and signal bus
3. Multi layer PCB structure, separate power lines and signal lines
4. Optimize ground wire layout to reduce electromagnetic interference between modules
5. High current routing design ensures stable power supply output
6. Slot contact electroplating treatment, антиокислительный, low contact impedance
7. Partition insulated wiring to avoid high voltage signal crosstalk
8. The mechanical positioning structure is precise, ensuring accurate card insertion and removal alignment
9. Equipped with power filter wiring to suppress power supply noise disturbance
10. The substrate has high mechanical strength and can withstand frequent insertion and slight vibration
11. Allocate power supply to the entire machine and deliver power to each functional board
12. Build an interconnection channel to achieve data exchange between different boards
13. Reserve test points for easy maintenance and troubleshooting of the entire machine’s circuit
14. Solder mask protective layer to resist the erosion of dust and moisture inside the chassis
15. Original factory size specifications, can directly replace the original backboard
The Jeol MP003380-00 backplane is the core interconnection carrier of the cabinet, which uniformly carries power supply and signal transmission, and realizes the collaborative work of various boards.
