JEOL PP01107-2 Electronic Board Module
Руководство по продукту：
JEOL PP01107-2 Electronic Board Module
1. Adapt JEOL electron microscope to achieve analog signal acquisition and conditioning
2. Amplify and filter weak sensing signals
3. The channels are independent of each other to prevent signal crosstalk
4. Integrated transient protection circuit to resist voltage spikes
5. Select high-precision components to ensure signal acquisition accuracy
6. Heat resistant substrate material, suitable for long-term working temperature of the chassis
7. Optimize wiring impedance and reduce analog signal transmission loss
8. Metallized through holes resist oxidation and extend service life
9. Signal isolation design to isolate external electromagnetic clutter interference
10. Quickly respond to signal changes and match the overall control timing of the machine
11. Reinforced welding process, with good seismic resistance
12. Real time upload of collected data to the main control
13. Standard board shape, compatible with the original installation position of the equipment
14. Solder mask coating protection reduces dust and moisture erosion
15. Original factory electrical calibration, spare parts can be directly replaced for use
The JEOL PP01107-2 electronic board module is responsible for sensor signal conditioning and conversion, providing accurate measurement data for the main control.
Подробные фотографии продукта：
PP01107-2
